Designation:

BTR-80 (GAZ 5903)

Info
Manufacturer: Military Industrial Company LLC - VPK
Product type: Armoured Vehicles
Name: Wheeled armoured personnel carrier

As indicated by armed conflicts, wheeled armored personnel carriers (APC's) are capable of considerably enhancing any army's combat potential. They are used to transport infantry units to the battlefield and engage in reconnaissance, combat security and patrolling, military cargo transportation, the towing of artillery guns and mortars. They are also used as medical and staff vehicles, mobile radio stations, recovery vehicles, repair shops, etc. In a number of cases they can accomplish fire support missions for infantry acting in combat formations. Developed by GAZ designers and manufactured since 1986 at Arzamas Engineering Plant, now known as AMZ joint stock company, the BTR-80 replaced previous versions, BTR-60PB and BTR-70. The BTR-80 armored personnel carrier is a four-axle, eight- wheeled vehicle, with all drive wheels, an independent suspension and water jet propulsion system. The APC is capable of following tanks and negotiating emplacements, trenches and water obstacles. It is equipped with ten seats to accommodate the personnel. The APC mounts devices for collective protection of the personnel from blast action and initial radiation during explosions of nuclear ammunition and from radioactive dust, bacteriological materials and toxic agents during the vehicle's operation on contaminated terrain. The vehicle is armed with a turret machine gun mount, designed to fight ground and low-flying air targets at ranges of up to 2,000 meters. The turret mount accommodates a 14.5-mm large-caliber machine gun (KPVT) and a coaxial 7.62-mm machine gun (PKT) with a traverse of 360° and an elevation of +60° to -4°. For battlefield illumination during night firing, there is an OU-3GA2M searchlight on the machine gun bracket. Six 3D6 smoke grenade launchers have been placed on the turret mount to provide smoke screens for camouflage purposes. The BTR-80's high mobility is ensured by the KamAZ-7403 turbocharged diesel engine, an eight-wheel drive, the wheels' independent torsion suspension, large ground clearance, and centralized tire air pressure control system. The engine is a V-form eight-cylinder, with a maximum power of 191 kW at 2,600 min-1 and a maximum torque of 785 Nm at 1,600-1,800 min-1.

Since 1993 the BTR-80 is powered by the YaMZ-238M2 with similar characteristics. Thanks to its design features, the BTR-80 can keep moving, even if one or two wheels are completely disabled. The vehicle remains totally intact, even if it hits an anti-personnel mine. If hit by an anti-tank mine, as proved in Afghanistan, it can keep moving as the blast energy normally damages only one of the eight wheels. The centralized tire air control system enables the driver to set pressure to suit changing movement conditions, ensuring low unit soil pressure and high cross-country capacity, which is comparable with tracked vehicles. The BTR-80 can use KI-80 or KI-126 bullet-resistant tires. Even when damaged by multiple hits of all calibers of bullets and in a total absence of air pressure, the BTR-80 can still keep going for another several hundred kilometers.

The BTR-80 is equipped with a self-recovery winch, mounted in the hull nose, with a tractive force of 43,120 - 60,000 N, which can be doubled with the aid of the pulley attached to the vehicle. The power unit preheater enhances the vehicle's combat readiness at low ambient temperatures, however, the design of the engine and its systems ensures the APC's start without preliminary heating, when the outside temperature is as low as minus 25 °C.

The semi-automatic fire extinguishing system for the power unit and two carbon dioxide fire extinguishers in the personnel compartment enhance the survivability of the armored personnel carrier. Thanks to the availability of four hatches, positioned in the hull roof, and two double-wing doors on the right and left sides of the vehicle its crew and infantry men can easily mount and dismount at a rapid pace. The bottom wing of the door forms a step as it is opened, thereby enabling mounting and dismounting, when the vehicle is on the move. In other words, the BTR-80 meets the best world standards, and even surpasses them in terms of some characteristics.

The BTR-80 surpasses its foreign counterparts in the following areas:


Specifications:
Property Value
Weight (kg)
13600
Crew
10
Length (mm)
7650
Width (mm)
2900
Track (mm)
2410
Max. road speed (km/h)
80
Max. water speed (km/h)
9
Max. road range (km)
600
Number of drive wheels
8
Number of wheels
8


Has folowing part:
Total Amount
1PN96 (Night gunner's sight)
1
1PZ (Gunner's sight)
1
5903-1013010-10 (Oil radiator)
1
5903-1013015-10 (Oil radiator)
1
5903-1301010 (Water radiator)
1
? (Explosive reactive armour)
1
KBA (Weapon station)
1
KI-120 (Tyre)
8
TKN-3MK (Commander's sighting system)
1
UTD-20 (Diesel engine)
1
YaMZ-238M2 (Power pack)
1
ZTM-1 (Turret)
1

BTR-80 (GAZ 5903) quantities:
Country Qnt
AFGHANISTAN AFGHANISTAN
10
ALGERIA ALGERIA
80
ARMENIA ARMENIA
50
AZERBAIJAN AZERBAIJAN
111
BANGLADESH BANGLADESH
1030
BELARUS BELARUS
195
COLOMBIA COLOMBIA
80
ESTONIA ESTONIA
32
FINLAND FINLAND
2
GEORGIA GEORGIA
26
HUNGARY HUNGARY
437
KAZAKHSTAN KAZAKHSTAN
100
KOREA KOREA
30
KYRGYZSTAN KYRGYZSTAN
454
MACEDONIA MACEDONIA
60
MOLDOVA MOLDOVA
11
NORTH KOREA NORTH KOREA
10
RUSSIA RUSSIA
2000
SIERRA LEONE SIERRA LEONE
20
SRI LANKA SRI LANKA
5
SUDAN SUDAN
60
TAJIKISTAN TAJIKISTAN
40
TURKEY TURKEY
141
TURKMENISTAN TURKMENISTAN
728
UKRAINE UKRAINE
444
UZBEKISTAN UZBEKISTAN
290
Qnt:
6446

Last Contracts:
Qnt Customer Value Add Date
(Close Date)
Unit cost
170
BANGLADESH

Dec 2015
(Dec 2016)

62
KAZAKHSTAN
$62.000.000
Feb 2007
(Nov 2008)
$1,000,000
36
INDONESIA
$18.000.000
Mar 2005
(Dec 2006)
$500,000
60
BANGLADESH
$17.500.000
Feb 2005
(Oct 2006)
$291,667
30
SUDAN
$15.000.000
Feb 2005
(Oct 2009)
$500,000
14
UGANDA
$7.000.000
Feb 2005
(Oct 2005)
$500,000
62
KAZAKHSTAN
$80.000.000
Feb 2004
(Oct 2007)
$1,290,323
12
INDONESIA
$6.500.000
Mar 2001
(Dec 2002)
$541,667
23
UZBEKISTAN
$8.000.000
Feb 2001
(Oct 2001)
$347,826
32
NORTH KOREA
$15.000.000
Feb 2000
(Nov 2001)
$468,750
30
SUDAN
$15.000.000
Feb 2000
(Oct 2002)
$500,000
19
SRI LANKA
$8.000.000
Feb 2000
(Oct 2001)
$421,053
Average Unit Cost:
$663,158
