Designation:

PVP XL

Info
Manufacturer: Societe de Constructions Panhard et Levassor
Product type: Armoured Vehicles
Name: Wheeled armoured personnel carrier

Similar to the PVP’s architecture, entering in service with the French army, the PVP XL was designed as a highly versatile protected platform capable of carrying eight fully-equipped soldiers in addition to the two-men crew or various C4ISR systems. Its armour achieves level 3 of the Nato Stanag and its ground clearance, as well as the shape of the hull, confers good protection against mines.

Specifications:
Property Value
Length (mm)
5382
Width (mm)
2500
Height (mm)
2326
Wheelbase (mm)
3550
Crew
2
Troops
8
Weight (kg)
7000
Payload (kg)
3000
Engine power output (h.p.)
270
Max. road speed (km/h)
120
Gradient (%)
60
Side slope (%)
30
Fording depth (mm)
1200
Max. road range (km)
800
