Designation:

CENTAURO MGS 120

Info
Manufacturer: Iveco - Oto Melara Consortium - CIO
Product type: Armoured Vehicles
Name: Fire support vehicle

•Crew 4+4 (opt.)

•New HITFACT 120mm Oto Melara turret

•Firing all NATO standard ammunitions 120mm

•Sighting and firing capability same as last generation MBT’s

•Superior strategic mobility (>100 m/h)

•High off-road mobility

•Excellent crew comfort

•Full NBC-safe operation

•High ballistic protection

Specifications:
Property Value
Main weapon caliber (mm)
120
Crew
4
Number of drive wheels
8
Number of wheels
8
Max. road speed (km/h)
105
Gradient (%)
60
Side slope (%)
30
Length (mm)
7850
Height (mm)
3035
Track (mm)
2505
Width (mm)
2945
Engine power output (h.p.)
520
Number of forward gears
5
Number of reverse gears
2
Ammunition of the main gun
35
Weight (kg)
25000
Auxiliary gun calibre (mm)
7.62
AA gun caliber (mm)
7.62
Planes of gun stabilization
2


Has folowing part:
Total Amount
Gtdrive (Stabilizer)
1
Hitfact (Antitank turret)
1
TURMS (Fire control system)
1
VCTA V6 (Diesel engine)
1
