Designation:

Leopardo 2A5E

Info
Manufacturer: General Dynamics Santa Barbara Sistemas
Product type: Armoured Vehicles
Name: Main battle tank

As the main contractor selected by the Spanish Government for the Leopard 2E Program, and in order to execute this contract, General Dynamics Santa Bárbara Sistemas has made a significant technological and management investment aimed at modernising its installations (machinery, tools and premises) as well as improving the capabilities of its technicians and workers.

The tank has the following basic technical features:

  • terms of weight and size, its weight in combat is 62.5 tons. It has a width with side armour of 3.78 m, a length with the cannon at 2h:11.3 m and with the cannon at 6h: 10.1 m and a maximum height of 3.65 metres.

  • In passing obstacles it has a capacity in crossing ditches of 2.9 m; in fording, its capacity reaches up to 1.2 m with the fording system conditioned, up to 2.23 m with on-board equipment, and up to 4 m with deep fording equipment, and the water input/output slopes of up to 15º. It clears vertical obstacles to a maximum height of 1.1 m and, lastly, has a roll proof manoeuvrability on lengthways slopes of 60% and on widthways slopes of 30%.

  • In terms of the mobility of the tank, its operating range is worth noting: 340 Km at 50 Km/h, with a capacity to reach a maximum speed of 68 Km/hour.

  • The armament consists of two 77 mm batteries of 8 launching tubes (6+2) (smoke and fragmentation) mounted on both sides of the tower. It also has a smooth-bore barrel Rheinmetall cannon, calibre 120 L55 mm, stabilised, with horizontal sector of fire of 360 degrees and vertical of -9 to 18+ degrees. Two 7.62 mm MG-3 machine guns, one coaxial with the cannon and the other on the tower.

Specifications:
Property Value
Weight (kg)
62500
Length (mm)
10100
Width (mm)
3740
Height (mm)
3650
Fording depth (mm)
4
Gradient (%)
60
Max. road range (km)
350
Engine power output (h.p.)
1500
Max. road speed (km/h)
70



Leopardo 2A5E quantities:
Country Qnt
SPAIN SPAIN
239
Qnt:
239

Last Contracts:
Qnt Customer Value Add Date
(Close Date)
Unit cost
219
SPAIN
$1.939.399.936
Mar 1998
(Dec 2012)
$8,855,707
Average Unit Cost:
$8,855,707
