Designation:

OWS-25R

 Info
Manufacturer: S.C. Mechanical Factory For Armament S.A. (SC MFA SA Mizil)
Product type: Turrets
Name: Owerhead weapon station

Optics:

  • Periscopic sight, with front window wiper & de-icer

  • Day: X1 window with aiming circle, X8 sight with ballistic reticule

  • Night: X7.5 passive night elbow, (generation 2+) (thermal imaging optional)

  • Observation periscopes, unity power, 4 periscopes PFI 240, on-command de-icing

Specifications:
Property Value
Main weapon caliber (mm)
25
Auxiliary gun calibre (mm)
7.62
AA gun caliber (mm)
12.7
Planes of gun stabilization
2
Traverse arc (degree)
360
Elevation (degree)
60
Depression (degree)
-11
Ammunition of the auxiliary gun
250
Ammunition of the main gun
200
Rate of fire (rds/min)
600
Slew rates in Azimuth (deg/sec)
45
Slew rates in Elevation (deg/sec)
45
Weight (kg)
1100
Number of guided missiles
2

Included in:
Product Amount
MLI-84M (Modernization of the vehicle)
1

Has folowing part:
Total Amount
KBA (Gun)
1
Spike-LR (Anti-tank guided missile launcher)
4
