Designation:

ARX 20

Info
Manufacturer: Nexter
Product type: Turrets
Name: Remote controlled weapon station

Nexter Systems have developed the ARX 20 to fill the gap between 0.50 cal (12.7 mm) and 30 mm remote weapon stations. It offers significantly greater firepower and range than the former without the platform limitations of the latter. The system uses the same weapon as the CP 20 armament kit which in turn was developed from an airborne weapon system. Suitable platforms would include HMMWV, VBL and VAB.

The 20mm cannon superior firepower

  • Provides stand-offs against heavily gunned asymetric threats.

  • Immediate stopping power.

  • Destroys light armoured vehicles.

Total crew protection

  • all functions (system operation, target detection and fire) are operated under protection.

  • Long range effectiveness (up to 2000m)

Main functions

  • Day / night observation over 360.

  • Fire on the move (Gyro-stabilised station)

  • Remotely-operated.

Easy integration on any carrier and for any mission

  • Reduced weight and compactness, low mechanical constraints on the carrier

  • Designrd to be integrated on different types of carriers, including light 4x4 vehicles

  • Well suited for security missions and for urban area combat

Specifications:
Property Value
Main weapon caliber (mm)
20
Weight (kg)
270
Elevation (degree)
60
Depression (degree)
-15
Elevation (degree)
60
Auxiliary gun calibre (mm)
7.62
Ammunition of the main gun
139

Included in:
Product Amount
ARAVIS (Tactical vehicle)
1
TITUS (Wheeled armoured personnel carrier)
1
V.B.R. Desert (Wheeled armoured personnel carrier)
1
VAB Mark II (Wheeled armoured personnel carrier)
1
VPK-233136 Tiger-M (Tactical vehicle)
1

Has folowing part:
Total Amount
20 M 621 (Gun)
1
