Designation:

CS/VP4 ATV

Info
Manufacturer: NORINCO - China North Industries Group Corporation - CNGC
Product type: Auxiliary Vehicles
Name: Lightweight troop carrier vehicle

The CS/VP4 Light All-Terrain Vehicle is 8x8 full-time driving type, having centre-turning function, compact design of the whole vehicle, high space utilization, strong carrying capability, low height of center of gravity, driving stability & maneuvering ability in the complicated terrains, and having amphibious driving ability. It is a new type special-operations vehicle for the troops to do battle & provide support in the special & complicated terrains like the mountain area, jungle, shoal, dessert, snow field, marsh, water area, etc. It is especially suitable to be used to transport personnel & carry light weaponry, and launch as a platform, and used for squad in special & complicated regions to conduct maneuvering operations like assault, reconnaissance, patrol, etc., as well as support tasks for material transport, etc. The CS/VP4 ATV has towing hook, hoisting ring and tie down rings design. The CS/ VP4 ATV features excellent campaign mobility and strategic mobility. It can be transported by commercial lorry, within or be hoisted by Mi-8, Mi-171 and CH-47 helicopters, and it can be transported by railway, ship or air freighter, and be air-dropped as well.

Features

  • Compact design of the whole vehicle, high space utilization, strong carrying capacity

  • Outstanding driving stability & maneuvering ability in the complicated terrains, and launch as a platform

  • It is ideal for squad in special & complicated regions to conduct maneuvering operations like assault, reconnaissance, patrol, etc., as well as military material support mission

  • Excellent campaign mobility and strategic mobility

Specifications:
Property Value
Crew
6
Number of wheels
8
Number of drive wheels
8
Weight (kg)
2850
Payload (kg)
1100
Length (mm)
3940
Height (mm)
1800
Width (mm)
1550
Engine power output (h.p.)
87
Max. road speed (km/h)
65
Max. water speed (km/h)
4
Gradient (%)
70
Side slope (%)
60
Ground clearance (mm)
270
Vertical obstacle (mm)
400
Trench (mm)
1200
Turning circle radius (mm)
2500
Max. road range (km)
400



CS/VP4 ATV quantities:
Country Qnt
CHINA CHINA
50
VENEZUELA VENEZUELA
10
Qnt:
60
