Designation:

AFV-420P Mosquito / HMV

Info
Manufacturer: Panus Assembly CO., LTD
Product type: Armoured Vehicles
Name: Wheeled armoured personnel carrier

Thai company Panus Assembly has unveiled a 4x4 military vehicle that it hopes to supply to the Royal Thai Armed Forces.

The HMV-420 high mobility vehicle (HMV) is based on the company’s HMV-150 platform, which was unveiled in 2017 and, in turn, is based on a re-engineered and upgraded Cadillac Gage V-150 Commando 4x4 light armoured vehicle.

In disclosing details about the HMV-420 in mid-September 2018, the company said it has been built to provide end-users with enhanced protection and a more spacious interior. The vehicle presumably derives its name from its Cummins 420hp engine, which has been integrated with an Allison 4500 SP automatic transmission.

Specifications:
Property Value
Number of wheels
4
Number of drive wheels
4
Engine power output (h.p.)
420
Weight (kg)
17000
Max. road range (km)
800
Max. road range (km)
110
Gradient (%)
60
Side slope (%)
30
Vertical obstacle (mm)
500
Crew
2
Troops
11
Length (mm)
6647
Width (mm)
2594
Height (mm)
3000


Has folowing part:
Total Amount
4500 SP (Transmission)
1
ISMe-420 (Euro 3) (Diesel engine)
1
