Designation:

GTK

Info
Manufacturer: Krauss-Maffei Wegmann GmbH & Co.KG - KMW
Product type: Armoured Vehicles
Name: Wheeled armoured personnel carrier

Specifications:
Property Value
Number of wheels
8
Number of drive wheels
8
Weight (kg)
26500
Length (mm)
7230
Width (mm)
2990
Height (mm)
2376
Ground clearance (mm)
504
Engine power output (h.p.)
545
Max. road speed (km/h)
104
Max. road range (km)
1100
Gradient (%)
60
Side slope (%)
30
Crew
10
Trench (mm)
2
Depth of fording, without preparation (mm)
0.8


Has folowing part:
Total Amount
6V199 TE20 (Diesel engine)
1
