Designation:

VCTP

Info
Manufacturer: TAMSE Tanqu Argentino Mediano Sociedad Del Estado
Product type: Armoured Vehicles
Name: Tracked armoured personnel carrier

Although allocated under Argentina the TAMSE VCTP was originally a German development, the firm of Thyssen having been awarded a 1974 contract by the Argentinean government for the development of a 105-mm gun tank and an IFV using the same basic chassis and hull.

Argentinean development and production of the VCTP IFV and it's variants was erratic due to the state of the local economy, to the point when production in Argentina was terminated after 350 examples (of all types, including the tank variant) out of planned 500 plus had been completed.

The basic VCTP IFV is essentially similar in layout to the German Marder but simplified and modified to meet Argentinean Army requirements and has a more powerful 720 hp MTU diesel power pack.

The main armament is carried in a two-man power-operated turret armed with a 20-mm Oerlikon cannon and an externally mounted 7.62-mm MG for air and local defence.

A further 7.62-mm MG is located in a remotely controlled mounting over the hull rear. This MG is controlled from within the troop compartment which can accommodate up to ten soldiers and their personal equipment. The troops enter and leave the vehicle via a door in the hull rear and there are also roof hatches.

Firing ports and vision devices are located around the troop compartment for use by the occupants. Four smoke grenade launchers are mounted each side overhaull. An essentially similar command post variant has provision for only sic in the troop compartment and lacks a turret, as does a 120-mm mortar carrier version (the VCTM) which has a crew of five.

An ARV version was produced in prototype form and only two 155-mm self-propelled guns (the VCA) were produced. The VCLC MLR was intended to fire 160- or 350-mm artillery rockets from preloaded 'packs' but only prototypes were completed for testing before production ceased.


Specifications:
Property Value
Weight (kg)
27500
Crew
2
Troops
10
Length (mm)
6790
Width (mm)
3280
Height (mm)
2450
Main weapon caliber (mm)
20
Auxiliary gun calibre (mm)
7.62
Engine power output (h.p.)
710
Max. road speed (km/h)
80
Max. road range (km)
570
Fording depth (mm)
1000


Has folowing part:
Total Amount
HSWL 204 (Transmission)
1
MB 833 Ka M-500 (Diesel engine)
1
MK 20 RH 202 (Gun)
1

VCTP quantities:
Country Qnt
ARGENTINA ARGENTINA
300
Qnt:
300
