Designation:

Type 85

Info
Manufacturer: NORINCO - China North Industries Group Corporation - CNGC
Product type: Armoured Vehicles
Name: Tracked armoured personnel carrier

The Tracked Armoured Fighting Vehicle Type 85 is a new type of tracked armoured fighting vehicle series developed in the middle of the 80's based on the contemporary ground warfare experience and requirements by China North Industries Corporation. Main vehicle types included in the Tracked Armoured Fighting Vehicle Series Types 85 are as follows:

1.Basic vehicle; Tracked Armoured Personnel Carrier Type 85;

2.Variants:

  • Armoured Command Vehicle type 85

  • NVH-1/4 Infantry Fighting Vehicle

  • Infantry Fighting Vehicle Type 85

  • Tracked Armoured Ambulance Type 85

  • 120 mm Self-propelled Mortar Type 85

  • 82 mm Self-propelled Mortar Type 85

  • 122 mm Self-propelled Howitzer Type 85

  • Recovery Vehicle Type 85

  • Maintenance Engineering Vehicle Type 85

Specifications:
Property Value
Crew
2
Troops
13
Weight (kg)
13600
Length (mm)
9500
Width (mm)
3060
Height (mm)
2590
Ground clearance (mm)
4460
Track (mm)
2526
Main weapon caliber (mm)
12.7
Ammunition of the main gun
1120
Engine power output (h.p.)
320
Number of cylinders
4
Rated speed (r.p.m.)
2500
Engine power output (h.p.)
65
Max. road speed (km/h)
45
Max. road range (km)
500
Gradient (%)
60
Side slope (%)
30
Trench (mm)
2200
Vertical obstacle (mm)
600



Type 85 quantities:
Country Qnt
THAILAND THAILAND
1400
Qnt:
1400
