Designation:

ACV SPM-120

Info
Manufacturer: FNSS Defence Systems Inc
Product type: Armoured Vehicles
Name: Mortar vehicle

Self-propelled mortar.

Specifications:
Property Value
Main weapon caliber (mm)
120
Number of smoke grenade launchers
6
Max. road speed (km/h)
65
Max. water speed (km/h)
6.3
Max. road range (km)
490
Gradient (%)
60
Side slope (%)
30
Vertical obstacle (mm)
740
Trench (mm)
1830
Power-to-weight ratio (h.p./t)
24.39
Engine power output (h.p.)
350
Number of forward gears
4
Number of reverse gears
1
Track link width (mm)
381
Length of track on ground (mm)
2680
Crew
4
Weight (kg)
12300
Length (mm)
5300
Width (mm)
2820
Height (mm)
2574
Ground pressure (kg/sm2)
0.65
Elevation (degree)
85
Traverse arc (degree)
42


Has folowing part:
Total Amount
6V53TA (Diesel engine)
1
X200-4B (Transmission)
1
