Designation:

Piranha IIIC

Info
Manufacturer: General Dynamics European Land Systems-Mowag GmbH
Product type: Armoured Vehicles
Name: Wheeled armoured personnel carrier

The PIRANHA IIIC amphibious has a length of 7.57 m, a width of 2.71 m, and a GVW of 18.5 t. The vehicle reaches a speed of up to 100 km/h on the road. The PIRANHA IIIC easily manages gradients of up to 60%, fording depths of up to 1.50 m and is able to swim up to a speed of 10 km/h. The 400 HP engine, together with the 7-speed automatic transmission, the modern independent wheel suspension, the tire pressure control system, and the disengageable all-wheel drive, give the PIRANHA IIIC a high degree of mobility even in difficult terrain. Moreover, the protection against ballistic threats and against mines provides the crew with a maximum degree of protection in a mission. The vehicle is equipped with all necessary features (NBC system, autonomous power supply, A/C system, etc.) that are required for the 24-hour operation of the integrated systems.

Specifications:
Property Value
Number of drive wheels
8
Number of wheels
8
Length (mm)
7570
Width (mm)
2710
Weight (kg)
18500
Max. road speed (km/h)
100
Gradient (%)
60
Max. water speed (km/h)
10
Engine power output (h.p.)
400
Number of forward gears
7




Last Contracts:
Qnt Customer Value Add Date
(Close Date)
Unit cost
26
SWITZERLAND

Nov 2007
(Dec 2011)

Average Unit Cost:

All contracts...
