Designation:

TZM122

Info
Manufacturer: Minotor-Service Unitary Enterprise
Product type: Armoured Vehicles
Name: Ammunition resupply vehicle

TZM122 Ammunition Carrier / Resupply Vehicle is designated for artillery ammunition storage and transportation.

TZM122 ammunition carrier enables:

  • advanced mobility and cross-country capability for a vehicle of the class

  • closer interoperability with firing units

  • battery ammunition allowance increase by 1.5 times (720 rounds versus 480 rounds)

  • enhanced survivability due to the crew and ammunition protection from bullets and fragmentations

  • direct transfer of artillery rounds into the 122mm 2S1 Gvozdika self-propelled howitzer

TZM122 resupply vehicle is distinguished by:

  • advanced armor protection of the crew and the ammunition

  • mobility, maneuverability and enhanced cross-country capability

  • amphibious capability

The use of the TZM122 Ammunition Carrier / Resupply Vehicle provides enhanced mobility and protection for self-propelled and towed artillery batteries.

The vehicle can be configured for transporting 130mm and 152mm artillery rounds.

Chassis - MT-LBu

Specifications:
Property Value
Weight (kg)
15000
Length (mm)
7300
Width (mm)
2900
Height (mm)
2570
Ground clearance (mm)
400
Ammunition of the main gun
80
Main weapon caliber (mm)
7.62
Max. road speed (km/h)
60
Max. road range (km)
500
Crew
2
Troops
4
