Designation:

ASCOD II (ULAN)

 Info
Manufacturer: General Dynamics European Land Systems-Steyr GmbH
Product type: Armoured Vehicles
Name: Infantry fighting vehicle

Development

The ASCOD (in Austria named ULAN and in Spain Pizarro) is a tracked armored vehicle in the class of 30 to 35 tons. The development of the ULAN began under the name ASCOD (Austrian-Spanish Cooperative Development) as a joint cooperation between General Dynamics Santa Bárbara Sistemas of Spain and Steyr-Daimler-Puch Spezialfahrzeug GmbH.

Specifications:
Property Value
Crew
3
Weight (kg)
31000
Ground pressure (kg/sm2)
0.72
Turning circle radius (mm)
8600
Max. road speed (km/h)
70
Length (mm)
6990
Width (mm)
3150
Height to hull top (mm)
1760
Ground clearance (mm)
450
Max. road range (km)
500
Fording depth (mm)
1500
Gradient (%)
75
Side slope (%)
40
Vertical obstacle (mm)
900
Main weapon caliber (mm)
30
Engine power output (h.p.)
720


Has folowing part:
Total Amount
8V199 (Diesel engine)
1
HSWL 106 (Transmission)
1
