Designation:

MXT-MV

Info
Manufacturer: Navistar International Corp.
Product type: Auxiliary Vehicles
Name: Truck

The MXT-MV (Military Extreme Truck - Military Version) was introduced in 2006. Part of International Truck's Military Vehicles line, it is an International MXT extensively modified for military duty, transportable by C-130.

Variants

Both variants are available with three different cab configurations: Standard, Extended Cab, and Crew Cab.

MXT-MV

Standard, unarmored version.

MXT-MVA (Armored)

The Plasan Sasa designed armored version, the MXT-MVA, has the choice of two removable armor kits, dubbed A-Kit and B-Kit, with increasing levels of protection against bullets, mines, and IEDs.

Husky TSV

The Husky is a variant of the MXT-MVA modified to satisfy the UK MoD's Tactical !Support Vehicles (TSV) requirements.

Navistar built its rejected M-ATV candidate sharing some powertrain & suspension components with the MXT, but with a completely unique chassis. This protection system was designed by Navistar rather than their normal MXT and MRAP partner, Plasan.

Armor protection

  • Full range of ballistic IED and mine blast protection solutions

Weapon systems

  • Compatible with multiple weapon systems

Additional features

  • Integral and A-kit/B-kit configurations

  • 360° crew protection

  • CTIS and runflats (optional)

  • Intelligent shock systems

  • Coil spring with straight axle

  • Right hand drive

Specifications:
Property Value
Number of wheels
4
Number of drive wheels
4
Crew
3
Length (mm)
6380
Width (mm)
2390
Height (mm)
2460
Wheelbase (mm)
3830
Weight (kg)
16659
Weight for transportation (kg)
14969
Payload (kg)
4309
Fording depth (mm)
1060
Turning circle radius (mm)
16150
Engine power output (h.p.)
340


Has folowing part:
Total Amount
6.0D (Diesel engine)
1

MXT-MV quantities:
Country Qnt
UNITED KINGDOM UNITED KINGDOM
351
Qnt:
351
