Designation:

Turkar Astevo

Info
Manufacturer: Hisarlar A.S.
Product type: Auxiliary Vehicles
Name: Truck

Thanks to its life-saving robust structure, it transports soldiers and supplies securely and safely even on the most severe terrain conditions. It is invincible, unyielding and unrelenting.

Technical Details

  • Suspension (Front-Rear): Parabolic Leaf Spring

  • Superstructure: Tactical and Logistical Services with Canvas

  • Capacity (Including the cab): 15 People

  • Seat Belt: With Four Points on Each Seat (For body seats)

  • Roll Protection: Area with Roll Bar

  • Transmission ZF 6S300 - ZF 6S350

  • Engine FPT F1A

Specifications:
Property Value
Length (mm)
4990
Width (mm)
2000
Height (mm)
2991
Wheelbase (mm)
2720
Max. road speed (km/h)
120
Turning circle radius (mm)
6000
Number of wheels
4
Number of drive wheels
4
Crew
3
Trench (mm)
12
Weight (kg)
5500
Payload (kg)
1920
Fuel capacity (l)
75
Engine power output (h.p.)
116
Maximum torque (Nm)
270
