Designation:

HMT Extenda

Info
Manufacturer: Supacat Ltd.
Product type: Auxiliary Vehicles
Name: Patrol Vehicle

Developed for use by Special Forces the Extenda provides a unique ‘convertible’ platform.

Using the HMT variable height air suspension system, Extenda matches the capabilities of the 400 and 600 series sister platforms yet can be configured as a 4x4 or 6x6 to meet the operational need by fitting or removing a modular, self-contained third axle unit. The hamper has also been designed as a modular system to enable rapid conversion.

Like the other HMT series variants, the Extenda can be supplied with an optional mine blast and ballistic protection kit and can be fitted with a variety of mission hampers, weapons, communications, ISTAR and force protection equipment to suit a wide range of operational roles.

Designed by Supacat, the HMT product is manufactured under licence from Lockheed Martin.

Specifications:
Property Value
Narrow field of view (degrees)
4
Number of wheels
6
Weight (kg)
10500
Length (mm)
7070
Width (mm)
2050
HEAT effective sighting range (m)
2445
Track (mm)
1700
Displacement (litres)
4250
Ground clearance (mm)
485
Payload (kg)
3900
Weight for transportation (kg)
6600
Turning circle radius (mm)
17500
Max. road speed (km/h)
120
Max. road range (km)
800
Fuel capacity (l)
200
Fording depth (mm)
1000
Gradient (%)
60
Side slope (%)
40
Engine power output (h.p.)
180
Number of forward gears
5


Has folowing part:
Total Amount
ISBe 6.7 180 (Diesel engine)
1

HMT Extenda quantities:
Country Qnt
AUSTRALIA AUSTRALIA
10
NEW ZEALAND NEW ZEALAND
5
Qnt:
15

Last Contracts:
Qnt Customer Value Add Date
(Close Date)
Unit cost
30
NEW ZEALAND

Jan 2017
(Dec 2020)

89
AUSTRALIA
$105.000.000
Aug 2014
(Dec 2017)
$1,179,775
Average Unit Cost:
$1,179,775
